Xerox WorkCentre 7132 Service Documentation

January 2007
2-599
WorkCentre 7132
045-327, 045-328
Status-indicator-raps
Revision
045-327 Marking Y RAP
BSD-ON:6.4/6.5
There is a marking Y plate error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
045-328 Marking M RAP
BSD-ON:6.4/6.5
There is a marking M plate error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
