Xerox WorkCentre 7132 Service Documentation

January 2007
2-737
WorkCentre 7132
094-421, 094-422
Status-indicator-raps
Revision
094-421 IBT Cleaner End of Life RAP
The IBT Cleaner reached end of life.
Initial Actions
Replace the IBT Belt Assembly (PL 6.1)
Procedure
Verify that the IBT Cleaner is at end of life (Detailed Maintenance Activities). The IBT Cleaner
is at end of life.
YN
Replace the MCU PWB (PL 11.1).
Replace the IBT Cleaner (PL 6.2).
094-422 2nd BTR End of Life RAP
The 2nd BTR reached end of life.
Initial Actions
Replace the IBT Belt Assembly (PL 6.1)
Procedure
Verify that the 2nd BTR is at end of life (Detailed Maintenance Activities). The 2nd BTR is at
end of life.
YN
Replace the MCU PWB (PL 11.1).
Replace the 2nd BTR (PL 2.7).
