Xerox WorkCentre 7132 Service Documentation

January 2007
2-693
WorkCentre 7132
078-210
Status-indicator-raps
Revision
078-210 TTM Tray 2 Lift RAP
BSD-ON:7.11
The Tray 2 Level Sensor did not actuate in time after the Tray 2 Feed/Lift Motor energized.
Initial Actions
Ensure the tray is set up and loaded correctly.
Procedure
Execute Component Control [072-001 or 002 Tray 2 Feed/Lift Motor ON]. The Tray 2 Feed/
Lift Motor /PL 15.6) can be heard (the lifted paper plate drops when the tray is opened).
YN
Check the connections of P/J220B, P/J661B and P/J549. P/J220B, P/J661B and P/
J549 are connected correctly.
YN
Connect P/J220B, P/J661B and P/J549.
Remove the Tray 1 Feed/Lift Motor (PL 2.3) and the Tray 2 Feed/Lift Motor (PL 15.6).
Replace the Tray 2 Feed/Lift Motor with the Tray 1 Feed/Lift Motor.
Execute Component Control [072-001/002 Tray 2 Feed/Lift Motor ON]. The Tray 2 Feed/
Lift Motor can be heard (the lifted paper plate drops when the tray is opened).
YN
Return the Tray 1 Feed/Lift Motor to its original position.
Check the wires between P/J220B and P/J549 for an open circuit or a short circuit
(BSD 7.11 Flag 1).
The circuit between P/J220B and P/J549 is conducting
without an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Replace the Tray Module PWB (PL 15.9).
Return the Tray 1 Feed/Lift Motor to its original position.
Replace the Tray 2 Feed/Lift Motor (PL 15.6).
Check the installation of the Tray 2 Level Sensor (PL 15.6) and the operation of the actuator.
The Tray 2 Level Sensor is installed correctly and the actuator works.
YN
Reinstall the Tray 2 Level Sensor (PL 15.6).
Execute Component Control [072-103 Tray 2 Level Sensor]. Manually activate the Tray 2 Level
Sensor (PL 15.6).
The display changes.
YN
Check the connections of P/J101B, P/J611 and P/J549. P/J102A, P/J611 and P/J409
are connected correctly.
YN
Connect P/J101B, P/J611 and P/J549.
Check the wires between P/J101B and P/J549 for an open circuit or a short circuit (BSD
7.11 Flag 2 Flag 3).
The wires between P/J101B and P/J549 are conducting without
an open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the Tray Module PWB P/J549-22 (+) and P/J549-23 (-)
(BSD 7.11 Flag 3).
The voltage is approx. +5VDC.
YN
Replace the Tray Module PWB (PL 15.9).
Measure the voltage between the Tray Module PWB P/J549-24 (+) and GND (-) (BSD
7.11 Flag 2).
Activate the actuator of the Tray 2 Level Sensor (PL 2.3). The voltage changes.
YN
Replace the Tray 2 Level Sensor (PL 15.6).
Replace the Tray Module PWB (PL 15.9).
Check the paper transport drives and repair as required (PL 2.3, PL 15.9).
A
A
