January 2007
2-702
WorkCentre 7132
089-630, 089-631
Revision
Status-indicator-raps
089-630 IOT Belt Speed RAP
IBT Belt speed failure.
Procedure
Check the following for binding:
• Fuser/ Main Drive (BSD 4.1A, 4.1B)
• Drum/IBT Auger Drives (BSD 4.2A, 4.2B)
• Developer Drive (BSD 4.3A)
• Registration (BSD 8.7)
• 1st BTR (BSD 9.5)
• 2BTR (BSD 9.7)
• IBT Belt and Cleaning (BSD 9.8)
• Fuser (BSD 10.3)
• Exit Transportation (BSD 10.4)
• Duplexing (BSD 10.6)
089-631 Belt Slip RAP
BSD-ON:9.8
IBT Belt slippage.
Initial Actions
Ensure that the IBT Belt tensioner is engaged.
Procedure
Execute Component Control [042-001 Main Motor]. Check the IBT Belt for slipping. The IBT
Belt is OK.
YN
Check the IBT Belt Assemblies for contamination, binding, and/or wear. IBT Belt Assem-
bly is OK.
YN
Replace the IBT Belt Assembly (PL 6.1).
Replace the IBT Belt (PL 6.2).
If the problem continues, replace the IBT Belt (PL 6.2). If the problem persists, replace the IBT
Belt Assembly (PL 6.1).
To Next Page
