Serial Number/Billing Meter Data
Purpose
Displays the Serial Number, Product Number, and Billing Data.1
Procedure
1. Enter UI Diagnostic Mode.
2. Select Adjustment/Others.
3. Select Machine ID/Billing Data.
NOTE: Serial Numbers, the Product Number, and Billing Data is displayed for IOT, Sys1,
and Sys2.
CAUTION
Failure to perform GP 4 Replacing Billing PWBs, if the MCU PWB, or the MCU PWB EPROM,
or the ESS PWB or the ESS PWB EPROM is replaced could result in NVM corruption and dis
-
abling the machine. Refer to REP 9.1.1 MCU PWB or REP 9.1.2 MCU PWB EPROM or REP
9.2.1 ESS PWB or REP 9.2.2 ESS PWB EPROM before installing a new MCU PWB, MCU
PWB EPROM, ESS PWB, or ESS PWB EPROM.
NOTE: GP 4 Replacing Billing PWBs, procedure is used to serialize components and load bill-
ing data on the new MCU PWB, or MCU PWB EPROM, or ESS PWB, or ESS PWB EPROM.
NOTE: Machine Serial Number Plate is located on side frame below rear yellow Fuser mount-
ing screw.
Printing HFSI
Procedure
1. Enter UI Diagnostic Mode).
2. Select NVM Read/Write.
3. Refer to Table 1 and enter a counter number for any High Frequency Service Item (HFSI)
counters to be checked.
Table 1 High Frequency Service Items
Counter Name Threshold Service Action to be performed
954-800
Reset
only
Tray 1 Feed counter 300K Replace the Feed Roll, Retard Roll, Nudger
Roll.
954-801 Tray 2 Feed counter 300K Replace the Feed Roll, Retard Roll, Nudger
Roll.
954-802 Tray 3 Feed counter 300K Replace the Feed Roll, Retard Roll, Nudger
Roll.
954-803 MSI Feed Roll /
Retard Pad
50K Replace the Feed Roll, Retard Pad
954-824 IBT Unit 480K Information not available at this time
954-825 IBT Cleaner Unit 100K Information not available at this time
954-826 BTR2 Unit 300K Replace the Bias Transfer Roll.
954-830 Developer time K 420K Replace K Developer Housing.
954-831 Developer time Y 420K Replace Y Developer Housing.
954-832 Developer time M 420K Replace M Developer Housing.
954-833 Developer time C 420K Replace C Developer Housing.
955-837 Xerographic Module 10M Replace the Xero Module
954-842 Fuser Assembly 10M Replace the Fuser Assembly
