January 2007
2-598
WorkCentre 7132
045-325, 045-326
Revision
Status-indicator-raps
045-325 Marking C RAP
BSD-ON:6.4/6.5
There is a marking C plate control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
045-326 Marking K RAP
BSD-ON:6.4/6.5
There is a marking K plate control error.
Procedure
Check the connections and wiring between the MCU PWB and the ROS Unit. The connec-
tions and wiring are OK.
YN
Repair replace as required (PL 11.1, PL 3.1).
Replace the MCU PWB (PL 11.1). If the problem continues, replace the ROS Unit (PL 3.1).
