January 2007
2-344
WorkCentre 7132
024-967
Revision
Status-indicator-raps
024-967 Mixed Width Paper (Staple Job) RAP
BSD-ON:3.4
Paper Width Mix was detected during stapling.
Initial Actions
• Power Off/On
Procedure
Check the connection of each MCU PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the connection of each Finisher PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the wire between J416 and J8843 for an open circuit or a short circuit (BSD 3.4 Flag 2/
Flag 1).
The wire between J416 and J8843 is conducting without an open circuit or a
short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB J416-A3 (+) and GND (-) (BSD 3.4 Flag 2). The
voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 11.1).
Replace the Finisher PWB (PL 17.12) If the problem persists, replace the MCU PWB (PL 11.1).
To Next Page
