January 2007
2-62
WorkCentre 7132
005-125, 005-126
Revision
Status-indicator-raps
Measure the voltage between the DADF PWB P754-1 (+) and GND (-), and between
P754-7 (+) and GND (-) (BSD 5.5 Flag 1).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 16.3).
Replace the DADF Feed Motor (PL 16.9) If the problem persists, replace the DADF PWB
(PL 15.3).
Execute Component Control [005-026]. The DADF Registration Motor (PL 16.9starts up.
YN
Check the connections of P/J765 and P/J755. P/J765 and P/J755 are connected cor-
rectly.
YN
Connect P/J765 and P/J755.
Check the wire between J765 and J755 for an open circuit or a short circuit (BSD 5.5 Flag
2).
The wire between J765 and J755 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P755-1 (+) and GND (-), and between
P755-6 (+) and GND (-) (BSD 5.5 Flag 2).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 16.3).
Replace the DADF Registration Motor (PL 16.9) If the problem persists, replace the
DADF PWB (PL 15.3).
Replace the DADF PWB (PL 16.3).
005-126 CVT Out Sensor On Jam
BSD-ON:5.4
Out Sensor does not turn On in specified time from Scan start (Reg. Motor start).
Procedure
If the problem occurs frequently, check the following:
1. There is any area in document path that interferes with document feed.
2. Any foreign substance is attached Roll surface.
3. Roll surface has worn abnormally.
4. Reg.Motor rotates normally.
5. Platen Motor rotates normally.
6. Check the connectors and wires for damage.
If all above are OK, replace Out Sensor (PL 16.9). If the problem persists, replace the DADF
PWB (PL 16.3).
A B
