January 2007
7-17
WorkCentre 7132
Plug/Jack Locations
Wiring-data
Reversion 4.0
Figure 10 ESS (j0tp7210)
P382
P380
J343
P351
J334
J333
J340
J344
J338
J330
J331
P304
P/J387
P/J388
