January 2007
2-99
WorkCentre 7132
005-907, 005-908
Status-indicator-raps
Revision
005-907 CVT Pre-Registration Sensor RAP
BSD-ON:5.4
Paper remains on the DADF Pre Registration Sensor.
Initial Actions
• Remove the paper.
• Power Off than On
Procedure
Execute Component Control [005-206 DADF Pre Registration Sensor]. Actuate the DADF Pre
Registration Sensor with paper.
The display changes.
YN
Check the connections of P/J781 and P/J761. P/J781 and P/J761 are connected cor-
rectly.
YN
Connect P/J781 and P/J761.
Check the wire between J781 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
3/Flag 4).
The wire between J781 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-12 (+) and GND (-) (BSD 5.4 Flag
4).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-11 (+) and GND (-) (BSD 5.4 Flag 3).
Actuate the DADF Pre Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Pre Registration Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
005-908 CVT Registration Sensor RAP
BSD-ON:5.4
Paper remains on the DADF Registration Sensor.
Initial Actions
• Remove the paper.
• Power Off than On
Procedure
Execute Component Control [005-110 DADF Registration Sensor]. Actuate the DADF Regis-
tration Sensor with paper. The display changes.
YN
Check the connections of P/J782 and P/J761. P/J782 and P/J761 are connected cor-
rectly.
YN
Connect P/J782 and P/J761.
Check the wire between J782 and J761 for an open circuit or a short circuit (BSD 5.4 Flag
1/Flag 2).
The wire between J782 and J761 is conducting without an open circuit or
a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P761-15 (+) and GND (-) (BSD 5.4 Flag
2).
The voltage is approx. +5VDC.
YN
Replace the DADF PWB (PL 16.3).
Measure the voltage between the DADF PWB P761-14 (+) and GND (-) (BSD 5.4 Flag 1).
Actuate the DADF Registration Sensor with paper. The voltage changes.
YN
Replace the DADF Registration Sensor (PL 16.7).
Replace the DADF PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
To Next Page
