January 2007
2-611
WorkCentre 7132
062-210 , 062-211
Status-indicator-raps
Revision
062-210 IIT Hot Line RAP
BSD-ON: 3.1
There is an open circuit in the cable between the IIT/IPS PWB and the ESS PWB.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the connection of each ESS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Check the wire between J720 and J320 for an open circuit or a short circuit (BSD 3.1 Flag 3/
Flag 4).
The wire between J720 and J320 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Replace the IIT/IPS PWB (PL 13.3)
If the problem persists, replace the ESS PWB (PL 11.2).
062-211 IIT/IPS PWB EEPROM RAP
BSD-ON: 3.1
The IPS EEPROM failed during the Read/Write operation.
Procedure
Check the connection of each IIT/IPS PWB connector. The connectors are securely con-
nected.
YN
Connect the connectors.
Switch on the power. The problem persists.
YN
Return to Service Call Procedures
Replace the IIT/IPS PWB (PL 13.3).
