Xerox WorkCentre 7132 Service Documentation

January 2007
2-125
WorkCentre 7132
010-336, 010-398
Status-indicator-raps
Revision
YN
Replace the Fuser Unit (PL 7.1).
Check the resistance of the Rear Thermistor between P615-12 and P615-11 (BSD 10.2 Flag 3/
Flag 2).
The resistance is 3k ohms or higher.
YN
Replace the Fuser Unit (PL 7.1).
Check the wire between J422 and J615 for an open circuit or a short circuit (BSD 10.2 Flag 3/
Flag 2).
The wire between J422 and J615 conducts with less than a few ohms.
YN
Repair the open circuit or short circuit.
Check the wire between J5 and J615 for an open circuit or a short circuit (BSD 10.2 Flag 1).
The wire between J5 and J615 conducts with less than a few ohms.
YN
Repair the open circuit or short circuit.
Check the wire between J409 and J513 for an open circuit or a short circuit (BSD 10.2 Flag 4).
The wire between J422 and J615 conducts with less than a few ohms.
YN
Repair the open circuit or short circuit.
Replace the Fuser Unit (PL 7.1). If the problem persists, replace the Power Unit (PL 11.1). If
the problem persists, replace the MCU PWB (PL 11.1).
010-398 Fuser Lock RAP
BSD-ON:10.3
The Fuser Fan failed.
Initial Actions
• Power Off/On
Procedure
Turn on the power.
Visually check the rotation of the Fuser Fan. The Fuser Fan is rotating.
YN
Measure the voltage between the MCU PWB J423-1 (+) and J423-4 (-) (BSD 10.3 Flag
1).
The voltage is approx. +24VDC.
YN
Replace the MCU PWB (PL 11.1).
Check the wires between MCU PWB and the Fuser Fan for an open or a short circuit
(BSD 10.3 Flag 1/Flag 3).
The wires between MCU PWB and the Fuser Fan conducts
with less than a few ohms.
YN
Repair the open circuit or short circuit.
Replace the Fuser Fan (PL 11.1).
Measure the voltage between the MCU PWB J423-3 (+) and GND (-) (BSD 10.3 Flag 4). The
voltage is approx. 0VDC.
YN
Check the wire between J423-3 and the Fuser Fan for an open circuit or a short circuit
(BSD 10.3 Flag 4).
The wire conducts with less than a few ohms.
YN
Repair the open circuit or short circuit.
Replace the Fuser Fan (PL 11.1).
Replace the MCU PWB (PL 11.1).
