Xerox WorkCentre 7132 Service Documentation

January 2007
2-686
WorkCentre 7132
077-900
Revision
Status-indicator-raps
077-900 Tray/Registration Sensor Jam RAP
BSD-ON:8.3, 8.7
Paper remains on the Registration Sensor.
Procedure
Enter Component Control [077-100 Registration Sensor]. Actuate the Registration Sensor (PL
2.5).
The display changes.
YN
Check the wires between P/J106 and P/J405 for an open circuit or a short circuit (BSD
8.7 Flag 1/Flag 2).
The circuit between P/J106 and P/J405 is conducting without an
open circuit or a short circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the MCU PWB P/J405-8A (+) and P/J405-6A (-) (BSD 8.7
Flag 2).
The voltage is approx. +5VDC.
YN
Replace the MCU PWB (PL 11.1).
Measure the voltage between the MCU PWB P/J405-A7 (+) and GND (-) (BSD 8.7 Flag
1).
Actuate the Registration Sensor with paper. The voltage changes.
YN
Replace the Registration Sensor (PL 2.5).
Replace the MCU PWB (PL 11.1).
Replace the MCU PWB (PL 11.1)
