711-003 DADF Lead Registration Adjustment (Side1)
(66.7mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-004 DADF Lead Registration Adjustment (Side1)
(75.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-005 DADF Lead Registration Adjustment (Side1)
(100.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-006 DADF Lead Registration Adjustment (Side1)
(133.3mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-007 DADF Lead Registration Adjustment (Side1)
(150.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-008 DADF Lead Registration Adjustment (Side1)
(200.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-009 DADF Lead Registration Adjustment (Side1)
(300.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-015 DADF Lead Registration Adjustment (Side2)
(37.5mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-016 DADF Lead Registration Adjustment (Side2)
(50.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-017 DADF Lead Registration Adjustment (Side2)
(66.7mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-018 DADF Lead Registration Adjustment (Side2)
(75.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-019 DADF Lead Registration Adjustment (Side2)
(100.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-020 DADF Lead Registration Adjustment (Side2)
(133.3mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-021 DADF Lead Registration Adjustment (Side2)
(150.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-022 DADF Lead Registration Adjustment (Side2)
(200.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-023 DADF Lead Registration Adjustment (Side2)
(300.0mm/sec)
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse)
711-029 DADF Tail Edge Fine Adjustment (Side1)
(37.5mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-030 DADF Tail Edge Fine Adjustment (Side1)
(50.0mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-031 DADF Tail Edge Fine Adjustment (Side1)
(66.7mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-032 DADF Tail Edge Fine Adjustment (Side1)
(75.0mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-033 DADF Tail Edge Fine Adjustment (Side1)
(100.0mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
711-034 DADF Tail Edge Fine Adjustment (Side1)
(133.3mm/sec)
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Tail Edge
adjustment = Lead Registration adjustment value + Tail Edge fine adjustment value
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
