January 2007
2-111
WorkCentre 7132
005-943
Status-indicator-raps
Revision
Check the wire between J787 and J786 for an open circuit or a short circuit (BSD 5.2 Flag
5).
The wire between J787 and J786 is conducting without an open circuit or a short
circuit.
YN
Repair the open circuit or short circuit.
Measure the voltage between the DADF PWB P786-1 (+) and GND (-) (BSD 5.2 Flag 5).
The voltage is approx. +24VDC.
YN
Replace the DADF PWB (PL 16.3).
Replace the DADF Nudger Motor (PL 16.6) If the problem persists, replace the DADF
PWB (PL 16.3).
Replace the DADF PWB (PL 16.3).
A B
To Next Page
