Xerox WorkCentre 7132 - Page 1355

January 2007
6-32
WorkCentre 7132
IOT NVM List
Reversion 4.0
General procedures information
746-143 1st BTR Resistance detection V monitor result storage (data4) 0 0~6500 1st BTR Resistance detection V monitor result storage (data4)
746-144 1st BTR Resistance detection V monitor result storage (data5) 0 0~6500 1st BTR Resistance detection V monitor result storage (data5)
746-145 1st BTR Resistance detection V monitor result storage (data6) 0 0~6500 1st BTR Resistance detection V monitor result storage (data6)
746-147 IBT CLN Auger Clutch On Timing (full speed) 0 0~255 IBT CLN Auger Clutch On Timing (full speed)
746-148 IBT CLN Auger Clutch On Timing (half speed) 0 0~255 IBT CLN Auger Clutch On Timing (half speed)
746-149 IBT CLN Auger Clutch Off Timing (BW_ full speed) 0 0~255 IBT CLN Auger Clutch Off Timing (BW_ full speed)
746-150 IBT CLN Auger Clutch Off Timing (FC_ full speed) 0 0~255 IBT CLN Auger Clutch Off Timing (FC_ full speed)
746-151 IBT CLN Auger Clutch Off Timing (BW_ half speed) 0 0~255 IBT CLN Auger Clutch Off Timing (BW_ halfspeed)
746-152 IBT CLN Auger Clutch Off Timing (FC_ half speed) 0 0~255 IBT CLN Auger Clutch Off Timing (FC_ halfspeed)
746-153 toner splash countermeasure (full speed) 0 0~3 toner splash countermeasure (full speed)
746-154 toner splash countermeasure (half speed) 0 0~3 toner splash countermeasure (halfspeed)
746-155 Flag is Over System Register Max Value 0 0~1 Flag is Over System Register Max Value
0: R>Rn
1: R>Rn
746-156 The concentration of the transcription Initial toner band 60 0~100 The concentration of the transcription Initial toner band
746-157 The concentration of the transcription toner band 60 0~100 The concentration of the transcription toner band
746-158 toner band execution environment NO. threshold value 0 0~9 toner band execution environment NO. threshold value
746-162 Transcription belt reverse execution switch (Job End) 1 0~1 Transcription belt reverse execution switch (Job End)
746-163 Transcription belt reverse environment NO. threshold value (Common) 5 0~9 Transcription belt reverse environment NO. threshold value (Common)
746-164 Transcription belt reverse quantity (at the time of usual) 50 0~100 Transcription belt reverse quantity (at the time of usual)
746-167 Resistance detection execution switch 1 0~1 Resistance detection execution switch
746-168 1st BTR Resistance detection standard electric current 200 0~800 1st BTR Resistance detection standard electric current
746-169 1st BTR fixed standard output I alpha Y 200 0~800 1st BTR fixed standard output I alpha Y
746-170 1st BTR fixed standard output I alpha M 200 0~800 1st BTR fixed standard output I alpha M
746-171 1st BTR fixed standard output I alpha C 200 0~800 1st BTR fixed standard output I alpha C
746-172 1st BTR fixed standard output I alpha K 350 0~800 1st BTR fixed standard output I alpha K
746-203 2nd BTR Resistance detection appropriate voltage 100 0~600 2nd BTR Resistance detection appropriate voltage
746-204 The second transcription department composition resistance calculation
result storage
0 0~10000 The second transcription department composition resistance calculation result
storage
746-205 The chosen the second transcription coefficient: alpha storage 0 0~6000 The chosen the second transcription coefficient: alpha storage
746-206 The chosen the second transcription coefficient: beta storage 0 0~6000 The chosen the second transcription coefficient: beta storage
746-207 2nd BTR resistance detection I monitor result storage (average) 0 0~6000 2nd BTR resistance detection I monitor result storage (average)
746-260 1st BTR Output (at the time of Diag) 200 0~800 1st BTR Output (at the time of Diag)
746-261 2nd BTR Output (at the time of Diag) 100 0~600 2nd BTR Output (at the time of Diag)
746-262 DTS Output (at the time of Diag) 30 0~30 DTS Output (at the time of Diag)
746-263 HFSI Life (IBT Unit_Life) 480000 0~1000000 HFSI Life (IBT Unit_Life)
746-264 HFSI Life (2nd BTR Unit_Life) 150000 0~1000000 HFSI Life (2nd BTR Unit_Life)
746-265 HFSI Life (IBT CLN Unit_Life) 100000 0~1000000 HFSI Life (IBT CLN Unit_Life)
746-266 Near End Warning (IBT Unit) 478500 0~1000000 Near End Warning (IBT Unit)
746-267 Near End Warning (2nd BTR Unit) 148500 0~1000000 Near End Warning (2nd BTR Unit)
746-268 Near End Warning (IBT CLN Unit) 98500 0~1000000 Near End Warning (IBT CLN Unit)
Table 5 Xfer
Chain-Link Name Default Range Description
