Xerox WorkCentre 7132 Service Documentation

January 2007
6-78
WorkCentre 7132
IIT NVM List
Reversion 4.0
General procedures information
711-071 T/A Roll Transport Speed Adjustment (Side1)
(50.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-072 T/A Roll Transport Speed Adjustment (Side1)
(66.7mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-073 T/A Roll Transport Speed Adjustment (Side1)
(75.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-074 T/A Roll Transport Speed Adjustment (Side1)
(100.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-075 T/A Roll Transport Speed Adjustment (Side1)
(133.3mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-076 T/A Roll Transport Speed Adjustment (Side1)
(150.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-077 T/A Roll Transport Speed Adjustment (Side1)
(200.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-078 T/A Roll Transport Speed Adjustment (Side1)
(300.0mm/sec)
15 0~50 0.001 Initial value 1.5% (15) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-080 T/A Roll Transport Speed Adjustment (Side2)
(37.5mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-081 T/A Roll Transport Speed Adjustment (Side2)
(50.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-082 T/A Roll Transport Speed Adjustment (Side2)
(66.7mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-083 T/A Roll Transport Speed Adjustment (Side2)
(75.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-084 T/A Roll Transport Speed Adjustment (Side2)
(100.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-085 T/A Roll Transport Speed Adjustment (Side2)
(133.3mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-086 T/A Roll Transport Speed Adjustment (Side2)
(150.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-087 T/A Roll Transport Speed Adjustment (Side2)
(200.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-088 T/A Roll Transport Speed Adjustment (Side2)
(300.0mm/sec)
0 0~50 0.001 Initial value 0% (0) Maximum 5% (50), Minimum 0% (0), 0.1% increments Adjusts
only Top Speed for Feed Motor.
711-140 DADF Lead Registration Adjustment (Side1)
Replace All
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse) Rewrites all
data of 711-001 to 711-009 with specified data.
711-141 DADF Lead Registration Adjustment (Side2)
Replace All
129 0~214 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -3.9mm (+85 pulse) Rewrites all
data of 711-015 to 711-023 with specified data.
711-142 DADF Tail Edge Fine Adjustment (Side1) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-029 to 711-037 with specified data.
711-143 DADF Tail Edge Fine Adjustment (Side2) Replace
All
129 0~255 0.0458mm Initial value 0mm (129 pulse) +5.9mm (-129 pulse) / -5.8mm (+126 pulse) Rewrites all
data of 711-043 to 711-051 with specified data.
711-144 Vertical Ratio Fine Adjustment Replace All 20 0~40 0.001 Initial value 0% (20) +/-2% (+/-20), 0.1% increments Adjusts only Top Speed for Feed
Motor and Regi Motor. Rewrites all data of 711-057 to 711-065 with specified data.
Table 2 CVT DADF NVM LIST
Chain-Link Content Default Range 1 Count Meaning
