January 2007
6-166
WorkCentre 7132
Controller & Fax NVM List
Reversion 4.0
General procedures information
870-027 Xfer: IBT Belt (IMPS) 0~99999999 - Read -
870-028 Xfer: IBT Belt (CYCLE) 0~99999999 - Read -
870-029 Xfer: 1st BTR 0~99999999 - Read -
870-030 Xfer: Backup Roll 0~99999999 - Read -
870-031 Xfer: 2nd BTR Unit 0~99999999 - Read -
870-032 Xfer: Bearing BTR 0~99999999 - Read -
870-033 Xfer: Trim within Transfer Module 0~99999999 - Read -
870-034 Xfer: Belt Cleaner Blade 0~99999999 - Read -
870-035 Xfer: Belt Cleaner Film Seal 0~99999999 - Read -
870-036 PH: No. of 1 Tray Feed 0~99999999 - Read -
870-037 PH: No. of MSI Feed 0~99999999 - Read -
870-038 PH: No. of 3TM 2Tray Feed 0~99999999 - Read -
870-039 PH: No. of 3TM 3Tray Feed 0~99999999 - Read -
870-040 PH: No. of 3TM 4Tray Feed 0~99999999 - Read -
870-041 PH: No. of 1TM 2Tray Feed 0~99999999 - Read -
870-042 PH: No. of TTM 2Tray Feed 0~99999999 - Read -
870-043 PH: No. of TTM 3Tray Feed 0~99999999 - Read -
870-044 PH: No. of TTM 4Tray Feed 0~99999999 - Read -
870-045 Fuser, NOHAD: PV (CV) Counter for
checking the replacement Life of the
Filter used for ROS contamination
0~99999999 - Read -
870-200 Input Tray Settings 0~9 1: Tray 1 Read/Write 0: Auto, 1: Tray 1, 2: Tray 2, 3: Tray 3, 4: Tray 4, 5: Tray 5, 6: SMH, 7:
HCF1, 8: HCF2, 9: Interposer
870-201 Output Tray Settings 0~255 1: Main Tray Read/Write 0: Auto, 1~255: Bin No
870-202 Copies (Output Sheet Count) Settings 1~65535 1: 1 set Read/Write 1~65535 sets
870-203 1 Sided Output/2 Sided Output Settings 0~2 0: 1 Sided Read/Write 0: 1 Sided, 1: 2 Sided (Head to Head), 2: 2 Sided (Head to Bottom)
870-204 Paper Type Settings 0~66 0: Plain Paper Read/Write 0: Plain Paper, 1: Recycled Paper, 2: Bond paper, 3: Lightweight, 4:
Heavyweight 1, 5: Heavyweight 2, 6: Heavyweight 1 Side 2, 7: Heavy
-
weight 2 Side 2, 8: Super Heavyweight, 9: Super Heavyweight Side 2, 10:
Transparency, 11: Tacked Paper, 12: Labels, 13~31: Plain Paper A~S, 32:
Heavyweight 1A, 33: Heavyweight 1B, 34: Heavyweight 1S, 35: Heavy
-
weight 1 (Side 2) A, 36: Heavyweight 1 (Side 2) B, 37: Heavyweight 1
(Side 2) S, 38: Heavyweight 2A, 39: Heavyweight 2B, 40: Heavyweight
2S, 41: Heavyweight 2 (Side 2) A, 42: Heavyweight 2 (Side 2) B, 43:
Heavyweight 2 (Side 2) S, 44: Heavyweight 1C, 45: Heavyweight 1C (Side
2), 46: Heavyweight 2C, 47: Heavyweight 2C (Side 2), 48: Heavyweight
2D, 49: Heavyweight 2D (Side 2), 50: Coated Paper 1, 51: Coated Paper 1
(Side 2), 52: Coated Paper 2, 53: Coated Paper 2 (Side 2), 54: Coated
Paper 1 Special (Special Glossy Paper), 55~59: Custom Paper 1~5, 60:
Tracing Paper, 61: Backing Paper, 62: Tab Paper Heavyweight 1, 63: Tab
Paper Heavyweight 2, 64: Labels 1, 65: Labels 2, 66: Perforated
(Punched)
870-205 Color Mode Settings 0~3 0: 4 Colors Read/Write 0: 4 Colors, 1: 3 Colors, 2: Mono Color, 3: BW
870-206 Single Color Settings 0~6 0: Black Read/Write 0: Black, 1: Yellow, 2: Magenta, 3: Cyan, 4: Red, 5: Green, 6: Blue
Table 15 Diagnostics
Chain-Link NVM Name Setup Range Initial Value Read/Write Description
