January 2007
6-219
WorkCentre 7132
Product Specs.
General procedures information
Reversion 4.0
Product Codes
Component Weights
Paper Capacities
Copy Speed
• Plain paper; simplex; fed from Tray 1 - 3
– Letter size LEF: 8/32ppm
– Letter size SEF: 8/16ppm
– Legal size: 8/32ppm
– A3/11x17 in.: 4/16ppm
FCOT/FPOT
First Copy Output Time (original on platen); 8.5” x 11” (A4); Tray 1;
• 27 sec. or less for color
• 16 sec. or less for monochrome
First Print Output Time (does not include ESS process time for prints); 8.5” x 11” (A4); Tray 1;
• 26 sec. max for color
• 15 sec. max for monochrome
Voltage Requirements
• Single phase (two wires plus ground)
• 110 - 127 VAC/60 Hz (99 - 135 VAC, 50/60 +/- 3 Hz)
• 220 - 240 VAC/50 Hz (198 to 254 VAC, 50/60 +/- 3 Hz)
Power Consumption (5 minute average)
• Machine Running: 1.33 kVA - NASG; 1.92 kVA ESG max.
• off Mode 1.5W~3.2W (Reference)
Environmental Data and Requirements
Ambient Temperature and Humidity requirement:
• Minimum: 10º C/50ºF at 15% humidity
• Maximum: 32º C/90ºF at 70% (28º C/82ºF at 85% humidity) humidity
IIT/DADF Specifications
Table 1 Product Codes WorkCentre 7132
No. Item Product Code
1 IOT/IIT 110V With OCT, 520 sheet tray, MSI, Duplex AYX
2 IOT/IIT GSA 110V WITH OCT, 520 sheet tray, MSI, Duplex AYXN
3 IOT/IIT 110V With DADF + TTM AYW
4 IOT/IIT 110V With DADF + Stand AYV
5 IOT/IIT 110V With Platen + Stand AYU
6 IOT/IIT 220V WITH OCT, 520 sheet tray, MSI, Duplex AYN
7 IOT/IIT 220V With DADF + TM AAP
5 2 TM 59F
6 TTM 00G
7 Finisher 00H
Table 2 Component Weights
Component Weight (approx.)
DC (Platen) 60 kg (132 lb.)
IIT and Platen 15 kg (33 lb.)
2 Tray Module 23 kg (51 lb.)
Tandem Tray Module 31 kg (68 lb.)
Exit2 2 kg (4 lb.)
Duplex Module 1.8 kg (4 lb.)
DADF 9.8 kg (30 lb.)
Finisher 30 kg (66 lb.)
Table 3 Paper Capacities
Specification Paper Trays 1 - 3 Tray 5 (Bypass)
Paper Sizes
• Min: 139.7W x 182L
• Max: 297W x 432Lmm
Paper
• Min: 89W x 98.4L mm (postcard)
• Max: 297W x 431.8L mm/12 x 19 in.
Paper Weights Range: 60 - 216 gsm (Tray 2
and 3)
Tray 1: 60 - 105 gsm
Range: 60 - 216 gsm
Capacities 20 lb.
(80 gsm)
TTM: 2620 sheets total:
• Tray 1: 520 sheets
• Tray 2: 900 sheets
• Tray 3: 1200 sheets
2TM: 1560 sheets total:
• Tray 1: 520 sheets
• Tray 2: 520 sheets
• Tray 3: 520 sheets
100 sheets
Table 4 DADF Specifications
Document Size: Platen Max size: 297 x 420 mm, 11 x 17 in.
Max scannable area: 297 x 420 mm
Table 3 Paper Capacities
Specification Paper Trays 1 - 3 Tray 5 (Bypass)
