FTT Fail To Train - Sent by receiving Fax - request to reduce send rate
GND Ground
HDD Hard Drive
HFSI High Frequency Service Item
HELLO Hello (HELO) identifies sender-SMTP to the receiver-SMTP
HVPS High Voltage Power Supply
Hz Hertz (Cycles per second)
IIT Image Input Terminal - Scanner/CCD portion of the machine
I/O Input/Output
IOT Image Output Terminal - ROS/Xero/paper handling/fusing portion of the machine
IQ Image Quality
JBIG Joint Bi-level Image Experts Group, an image compression scheme
JCL Job Control Language
KBPS Kilo Bites Per Second
KC 1000 copies
KO Key Operator
LCD Liquid Crystal Display
LDAP Lightweight Directory Access Protocol
LE Lead Edge of copy or print paper, with reference to definition of term TE
LED Light Emitting Diode
LEF Long Edge Feed
LTR Letter size paper (8.5 x 11 inches)
LUT Look Up Table - array of NVM locations that store process control data
LVPS Low Voltage Power Supply
LZW Lempel, Ziv, Welchan, an image compression scheme
MF Multi-Function
MN Multinational
NIC Network Interface Card
NA North America
NAAO North American Agent Operations
NARS North American Reseller Sales
NG Not Good, No Good
NO Number
NVM Non Volatile Memory
OEM Original equipment manufacturer
OGM On-going Maintenance
Panther Continuous data protection protocol or utility
PC Personal Computer
PCL Printer Control Language
PDF Portable Document Format
PDL Page Description Language
Table 1
Term Description
Phase A,
B, C, D, E
Phase A is Fax call set up, Phase B is pre-message processing, Phase C is mes-
sage transmission, Phase D is post message protocols, Phase E is Release Fax call
PJ Plug Jack (electrical connections)
PJL Printer Job Language
PL Parts List
PO Part of (Assembly Name)
POP Post Office Protocol
PWB Printed Wiring Board
PWS Portable Workstation for Service
RAM Random Access Memory
RAP Repair Analysis Procedure for diagnosis of machine status codes and abnormal con-
ditions.
R/E Reduction/Enlargement refers to features selection or components that enable
reduction or enlargement.
REP Repair Procedure for disassembly and reassembly of component on machine
RIS Raster Input Scanner
ROM Read Only Memory
ROS Raster Output Scanner. Device that transfers digitally processed image, using laser
light, to photoreceptor.
SAD Solid Area Density
SCP Service Call Procedure
SEF Short Edge Feed
Self-test An automatic process that is used to check Control Logic circuitry. Any fault that is
detected during self-test is displayed by fault code or by LEDs on PWB.
SIMM Single Inline Memory Module used to increase printing capacity
SMB Server Message Block
SMTP Simple Mail Transfer Protocol
Simplex Single sided copies
SSL Secure Socket(s) Link
SUB Sub-addressed - indicates that the following facsimile information field (FIF) informa-
tion is sub-addressed in the called subscriber's domain.
SW Software
TCP/IP Transmission Control Protocol/Internet Protocol
TE Trail Edge of copy or print paper, with reference to definition of term LE
TIFF Tag Image File Format
UM Unscheduled Maintenance
UI User Interface
USB Universal Serial Bus
V.8 A part of the initial Fax transmission phase when attributes are worked between
sending and receiving fax machines
W/ With - indicates machine condition where specified condition is present
W/O Without - indicates machine condition where specified condition is not present
Table 1
Term Description
