ADSP-21368 SHARC Processor Hardware Reference 4-39
Digital Audio/Digital Peripheral Interfaces
Figure 4-34. SRU_PIN4 Register
Table 4-7. Group D Sources—Pin Signal Assignments
Selection Code Source Signal Description (Source)
0000000 (0x0) DAI_PB01_O Select DAI pin buffer 1
0000001 (0x1) DAI_PB02_O Select DAI pin buffer 2
0000010 (0x2) DAI_PB03_O Select DAI pin buffer 3
0000011 (0x3) DAI_PB04_O Select DAI pin buffer 4
0000100 (0x4) DAI_PB05_O Select DAI pin buffer 5
0000101 (0x5) DAI_PB06_O Select DAI pin buffer 6
0000110 (0x6) DAI_PB07_O Select DAI pin buffer 7
0000111 (0x7) DAI_PB08_O Select DAI pin buffer 8
0001000 (0x8) DAI_PB09_O Select DAI pin buffer 9
0001001 (0x9) DAI_PB10_O Select DAI pin buffer 10
0001010 (0xA) DAI_PB11_O Select DAI pin buffer 11
0001011 (0xB) DAI_PB12_O Select DAI pin buffer 12
0001100 (0xC) DAI_PB13_O Select DAI pin buffer 13
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
1000001010110100
Reserved
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0010011111001111
DAI_PB19_I
DAI_PB19_I
DAI_PB18_I
DAI_PB17_I
DAI_PB20_I
SRU_PIN4 (0x2464)
DAI Pin Buffer 19 Input
DAI Pin Buffer 17 Input
DAI Pin Buffer 18 Input
DAI Pin Buffer 20 Input
DAI Pin Buffer 19 Input
Reset = 0x05694F9E
