Making Connections in the SRUs
4-40 ADSP-21368 SHARC Processor Hardware Reference
0001101 (0xD) DAI_PB14_O Select DAI pin buffer 14
0001110 (0xE) DAI_PB15_O Select DAI pin buffer 15
0001111 (0xF) DAI_PB16_O Select DAI pin buffer 16
0010000 (0x10) DAI_PB17_O Select DAI pin buffer 17
0010001 (0x11) DAI_PB18_O Select DAI pin buffer 18
0010010 (0x12) DAI_PB19_O Select DAI pin buffer 19
0010011 (0x13) DAI_PB20_O Select DAI pin buffer 20
0010100 (0x14) SPORT0_DA_O Select SPORT 0A data
0010101 (0x15) SPORT0_DB_O Select SPORT 0B data
0010110 (0x16) SPORT1_DA_O Select SPORT 1A data
0010111 (0x17) SPORT1_DB_O Select SPORT 1B data
0011000 (0x18) SPORT2_DA_O Select SPORT 2A data
0011001 (0x19) SPORT2_DB_O Select SPORT 2B data
0011010 (0x1A) SPORT3_DA_O Select SPORT 3A data
0011011 (0x1B) SPORT3_DB_O Select SPORT 3B data
0011100 (0x1C) SPORT4_DA_O Select SPORT 4A data
0011101 (0x1D) SPORT4_DB_O Select SPORT 4B data
0011110 (0x1E) SPORT5_DA_O Select SPORT 5A data
0011111 (0x1F) SPORT5_DB_O Select SPORT 5B data
0100000 (0x20) SPORT0_CLK_O Select SPORT 0 clock
0100001 (0x21) SPORT1_CLK_O Select SPORT 1 clock
0100010 (0x22) SPORT2_CLK_O Select SPORT 2 clock
0100011 (0x23) SPORT3_CLK_O Select SPORT 3 clock
0100100 (0x24) SPORT4_CLK_O Select SPORT 4 clock
Table 4-7. Group D Sources—Pin Signal Assignments (Cont’d)
Selection Code Source Signal Description (Source)
To Next Page
