Making Connections in the SRUs
4-46 ADSP-21368 SHARC Processor Hardware Reference
01100 (0xC) DAI_PB13_O Select DAI pin buffer 13 output
01101 (0xD) DAI_PB14_O Select DAI pin buffer 14 output
01110 (0xE) DAI_PB15_O Select DAI pin buffer 15 output
01111 (0xF) DAI_PB16_O Select DAI pin buffer 16 output
10000 (0x10) DAI_PB17_O Select DAI pin buffer 17 output
10001 (0x11) DAI_PB18_O Select DAI pin buffer 18 output
10010 (0x12) DAI_PB19_O Select DAI pin buffer 19 output
10011 (0x13) DAI_PB20_O Select DAI pin buffer 20 output
10100 (0x14) SPORT0_F0_O Select serial port0 frame sync
10101 (0x15) SPORT1_FS_O Select serial port1 frame sync
10110 (0x16) SPORT2_FS_O Select serial port2 frame sync
10111 (0x17) SPORT3_FS_O Select serial port3 frame sync
11000 (0x18) SPORT4_FS_O Select serial port4 frame sync
11001 (0x19) SPORT5_FS_O Select serial port5 frame sync
11010 (0x1A) PCG_CLKA_O Select precision clock A
11011 (0x1B) PCG_FSA_O Select precision frame sync A
11100 (0x1C) PCG_CLKB_O Select precision clock B
11101 (0x1D) PCG_FSB_O Select precision frame sync B
11110 (0x1E) LOW Select logic level low (0) as a source
11111 (0x1F) HIGH Select logic level high (1) as a source
Table 4-8. Group E Sources—Miscellaneous Signals (Cont’d)
Selection Code Source Signal Description (Output Source)
