ADSP-21368 SHARC Processor Hardware Reference 4-45

Digital Audio/Digital Peripheral Interfaces

Figure 4-36. SRU_MISCB Register

Table 4-8. Group E Sources—Miscellaneous Signals

Selection Code Source Signal Description (Output Source)

00000 (0x0) DAI_PB01_O Select DAI pin buffer 1 output

00001 (0x1) DAI_PB02_O Select DAI pin buffer 2 output

00010 (0x2) DAI_PB03_O Select DAI pin buffer 3 output

00011 (0x3) DAI_PB04_O Select DAI pin buffer 4 output

00100 (0x4) DAI_PB05_O Select DAI pin buffer 5 output

00101 (0x5) DAI_PB06_O Select DAI pin buffer 6 output

00110 (0x6) DAI_PB07_O Select DAI pin buffer 7 output

00111 (0x7) DAI_PB08_O Select DAI pin buffer 8 output

01000 (0x8) DAI_PB09_O Select DAI pin buffer 9 output

01001 (0x9) DAI_PB10_O Select DAI pin buffer 10 output

01010 (0xA) DAI_PB11_O Select DAI pin buffer 11 output

01011 (0xB) DAI_PB12_O Select DAI pin buffer 12 output

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

1001111011110111

Reserved

15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

0011110111101111

DAI Interrupt 27

DAI_INT_27

DAI Interrupt 25

DAI_INT_25

DAI Interrupt 26

DAI_INT_26

DAI Interrupt 22

DAI_INT_22

DAI Interrupt 23

DAI_INT_23

DAI Interrupt 24

DAI_INT_24

SRU_MISCB (0x2471)

DAI_INT_25

DAI Interrupt 25

Reset = 0x3DEF7BDE
