Making Connections in the SRUs
4-50 ADSP-21368 SHARC Processor Hardware Reference
001101 (0xD) SPORT1_FS_PBEN_O Select serial port 1 frame sync output enable
001110 (0xE) SPORT1_DA_PBEN_O Select serial port 1 data channel A output enable
001111 (0xF) SPORT1_DB_PBEN_O Select serial port 1 data channel B output enable
010000 (0x10) SPORT2_CLK_PBEN_O Select serial port 2 clock output enable
010001 (0x11) SPORT2_FS_PBEN_O Select serial port 2 frame sync output enable
010010 (0x12) SPORT2_DA_PBEN_O Select serial port 2 data channel A output enable
010011 (0x13) SPORT2_DB_PBEN_O Select serial port 2 data channel B output enable
010100 (0x14) SPORT3_CLK_PBEN_O Select serial port 3 clock output enable
010101 (0x15) SPORT3_FS_PBEN_O Select serial port 3 frame sync output enable
010110 (0x16) SPORT3_DA_PBEN_O Select serial port 3 data channel A output enable
010111 (0x17) SPORT3_DB_PBEN_O Select serial port 3 data channel B output enable
011000 (0x18) SPORT4_CLK_PBEN_O Select serial port 4 clock output enable
011001 (0x19) SPORT4_FS_PBEN_O Select serial port 4 frame sync output enable
011010 (0x1A) SPORT4_DA_PBEN_O Select serial port 4 data channel A output enable
011011 (0x1B) SPORT4_DB_PBEN_O Select serial port 4 data channel B output enable
011100 (0x1C) SPORT5_CLK_PBEN_O Select serial port 5 clock output enable
011101 (0x1D) SPORT5_FS_PBEN_O Select serial port 5 frame sync output enable
011110 (0x1E) SPORT5_DA_PBEN_O Select serial port 5 data channel A output enable
011111 (0x1F) SPORT5_DB_PBEN_O Select serial port 5 data channel B output enable
100000 (0x20) SPORT6_CLK_PBEN_O Select serial port 6 clock output enable
100001 (0x21) SPORT6_FS_PBEN_O Select serial port 6 frame sync output enable
100010 (0x22) SPORT6_DA_PBEN_O Select serial port 6 data channel A output enable
100011 (0x23) SPORT6_DB_PBEN_O Select serial port 6 data channel B output enable
100100 (0x24) SPORT7_CLK_PBEN_O Select serial port 7 clock output enable
Table 4-9. Group F Sources—Pin Output Enable (Cont’d)
Selection Code Source Signal Description (Output Source)
