ADSP-21368 SHARC Processor Hardware Reference 4-63
Digital Audio/Digital Peripheral Interfaces
001101 13 SPIFLG0_PE_O Pin enable for slave select 0 from SPI
001110 14 SPIFLG1_PE_O Pin enable for slave select 1 from SPI
001111 15 SPIFLG2_PE_O Pin enable for slave select 2 from SPI
010000 16 SPIFLG3_PE_O Pin enable for slave select 3 from SPI
010001 17 SPIBMISO_PE_O Pin enable for MISO from SPIB
010010 18 SPIBMOSI_PE_O Pin enable for MOSI from SPIB
010011 19 SPIBCLK_PE_O Pin enable for CLK from SPIB
010100 20 SPIBFLG0_PE_O Pin enable for slave select 0 from SPIB
010101 21 SPIBFLG1_PE_O Pin enable for slave select 1 from SPIB
010110 22 SPIBFLG2_PE_O Pin enable for slave select 2 from SPIB
010111 23 SPIBFLG3_PE_O Pin enable for slave select 3 from SPIB
011000 24 FLAG4_PE_O Pin enable for Flag 4 output
011001 25 FLAG5_PE_O Pin enable for Flag 5 output
011010 26 FLAG6_PE_O Pin enable for Flag 6 output
011011 27 FLAG7_PE_O Pin enable for Flag 7 output
011100 28 FLAG8_PE_O Pin enable for Flag 8 output
011101 29 FLAG9_PE_O Pin enable for Flag 9 output
011110 30 FLAG10_PE_O Pin enable for Flag 10 output
011111 31 FLAG11_PE_O Pin enable for Flag 11 output
100000 32 FLAG12_PE_O Pin enable for Flag 12 output
100001 33 FLAG13_PE_O Pin enable for Flag 13 output
100010 34 FLAG14_PE_O Pin enable for Flag 14 output
100011 35 FLAG15_PE_O Pin enable for Flag 15 output
100100 36 TWI_SDATA_OE Serial data output enable from TWI
Table 4-13. Group C Signals (Cont’d)
Binary Decimal Signal Description
