Processor Pin Descriptions
14-10 ADSP-21368 SHARC Processor Hardware Reference
Figure 14-3. FLAGS Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
U0U0U0U0U0U0U0U0
FLG15O
FLAG15 Output Select
FLG15
FLAG15 Value
FLG14O
FLAG14 Output Select
FLG14
FLAG14 Value
FLG13O
FLAG13 Output Select
FLG13
FLAG13 Value
FLG12O
FLAG12 Output Select
FLG12
FLAG12 Value
FLG8
FLAG8 Value
FLG8O
FLAG8 Output Select
FLG9
FLAG9 Value
FLG9O
FLAG9 Output Select
FLG10
FLAG10 Value
FLG10O
FLAG10 Output Select
FLG11
FLAG11 Value
FLG11O
FLAG11 Output Select
-For all FLGx bits, FLAGx values are as follows: 0=LOW, 1=HIGH.
-For all FLGxO bits, FLAGx output selects are as follows: 0=FLAGx Input, 1=FLAGx Output.
-U indicates the bit value is unknown at reset.
FLAGS
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
U0U0U0U0U0U0U0U0
FLG7O
FLAG7 Output Select
FLG7
FLAG7 Value
FLG6O
FLAG6 Output Select
FLG6
FLAG6 Value
FLG5O
FLAG5 Output Select
FLG5
FLAG5 Value
FLG4O
FLAG4 Output Select
FLG4
FLAG4 Value
FLG0
FLAG0 Value
FLG0O
FLAG0 Output Select
FLG1
FLAG1 Value
FLG1O
FLAG1 Output Select
FLG2
FLAG2 Value
FLG2O
FLAG2 Output Select
FLG3
FLAG3 Value
FLG3O
FLAG3 Output Select
