DAI/DPI Registers
A-114 ADSP-21368 SHARC Processor Hardware Reference
Figure A-44. DAI Interrupt Latch Register
Table A-46. DAI Interrupt Registers
Register Description Address
DAI_IRPTL_H
DAI_IRPTL_HS
High Priority Interrupt Latch Register
Shadow High Priority Interrupt Latch Register
0x2488
0x248C
DAI_IRPTL_L
DAI_IRPTL_LS
Low Priority Interrupt Latch Register
Shadow Low Priority Interrupt Latch Register
0x2489
0x248D
DAI_IRPTL_PRI Core Interrupt Priority Assignment Register 0x2484
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
0000000000000000
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0000000000000000
SRC0_MUTE_INT
IDP_DMA3_INT
SRU_EXTMISCA3_INT
ISRU_EXTMISCB1_INT
IDP_DMA7_INT
IDP_DMA6_INT
IDP_DMA2_INT
IDP_DMA1_INT
IDP_DMA0_INT
IDP_FIFO_GTN_INT
SPDIF_RX_VALID
ISRU_EXTMISCB0_INT
SRU_EXTMISCA2_INT
SRU_EXTMISCA1_INT
SRU_EXTMISCA0_INT
SRU_EXTMISCB5_INT
SRU_EXTMISCB4_INT
SRU_EXTMISCB3_INT
ISRU_EXTMISCB2_INT
SRC2_MUTE_INT
SRC1_MUTE_INT
SRC3_MUTE_INT
SPDIF_RX_LOCK_START
SPDIF_RX_CRC_ERROR
SPDIF_RX_NO_STREAM
SPDIF_RX_PARITY_ERROR
SPDIF_RX_NON_AUDIO
SPDIF_RX_EMPHASIS
SPDIF_RX_CH_STAT_CHNG
IDP_FIFO_OVR_INT
IDP_DMA4_INT
IDP_DMA5_INT
DAI_IRPTL_RE(0x2480) DAI_IRPTL_FE(0x2481)
DAI_IRPTL_PRI(0x2484) DAI_IRPTL_H(0x2488)
DAI_IRPTL_L(0x2489) DAI_IRPTL_HS(0x248C)
DAI_IRPTL_LS(0x248D)
