Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 113 of 1823
Jul 31, 2019
RX23W Group 5. I/O Registers
0008 90E7h S12AD A/D Sampling State Register 7 ADSSTR7 8 8 2 or 3 PCLKB 2 ICLK section 44.
0008 A020h SCI1 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A020h SMCI1 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A021h SCI1 Bit Rate Register BRR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A022h SCI1 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A022h SMCI1 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A023h SCI1 Transmit Data Register TDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A024h SCI1 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A024h SMCI1 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A025h SCI1 Receive Data Register RDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A026h SCI1 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A026h SMCI1 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A027h SCI1 Serial Extended Mode Register SEMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A028h SCI1 Noise Filter Setting Register SNFR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A029h SCI1 I
2
C Mode Register 1 SIMR1 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Ah SCI1 I
2
C Mode Register 2 SIMR2 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Bh SCI1 I
2
C Mode Register 3 SIMR3 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Ch SCI1 I
2
C Status Register SISR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Dh SCI1 SPI Mode Register SPMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Eh SCI1 Transmit Data Register HL TDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 A02Eh SCI1 Transmit Data Register H TDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A02Fh SCI1 Transmit Data Register L TDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A030h SCI1 Receive Data Register HL RDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 A030h SCI1 Receive Data Register H RDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A031h SCI1 Receive Data Register L RDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A032h SCI1 Modulation Duty Register MDDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A0h SCI5 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A0h SMCI5 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A1h SCI5 Bit Rate Register BRR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A2h SCI5 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A2h SMCI5 Serial Control Register SCR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A3h SCI5 Transmit Data Register TDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A4h SCI5 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A4h SMCI5 Serial Status Register SSR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A5h SCI5 Receive Data Register RDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A6h SCI5 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A6h SMCI5 Smart Card Mode Register SCMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A7h SCI5 Serial Extended Mode Register SEMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A8h SCI5 Noise Filter Setting Register SNFR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0A9h SCI5 I
2
C Mode Register 1 SIMR1 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0AAh SCI5 I
2
C Mode Register 2 SIMR2 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0ABh SCI5 I
2
C Mode Register 3 SIMR3 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0ACh SCI5 I
2
C Status Register SISR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0ADh SCI5 SPI Mode Register SPMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0AEh SCI5 Transmit Data Register HL TDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 A0AEh SCI5 Transmit Data Register H TDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0AFh SCI5 Transmit Data Register L TDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0B0h SCI5 Receive Data Register HL RDRHL 16 16 4 or 5 PCLKB 2 ICLK section 33.
0008 A0B0h SCI5 Receive Data Register H RDRH 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0B1h SCI5 Receive Data Register L RDRL 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A0B2h SCI5 Modulation Duty Register MDDR 8 8 2 or 3 PCLKB 2 ICLK section 33.
0008 A100h SCI8 Serial Mode Register SMR 8 8 2 or 3 PCLKB 2 ICLK section 33.
Table 5.1 List of I/O Registers (Address Order) (9/31)
Address
Module
Symbol Register Name
Register
Symbol
Number
of Bits
Access
Size
Number of Access Cycles
Reference
SectionICLK  PCLK ICLK <PCLK
