RX23W Group 51. Electrical Characteristics
51.15.3 Reception Characteristics (1 Mbps)
Note: The characteristics are based on pins and functions other than those for the BLE interface not being in use.
Note 1. PER ≤ 30.8%, and a 37-byte payload
Note 2. Allowable range of difference between the center frequency for the RF input signals and the carrier frequency generated within
the chip
51.15.4 Reception Characteristics (500 kbps)
Note: The characteristics are based on pins and functions other than those for the BLE interface not being in use.
Note 1. PER ≤ 30.8%, and a 37-byte payload
Note 2. Allowable range of difference between the center frequency for the RF input signals and the carrier frequency generated within
the chip
Table 51.63 Reception Characteristics
Conditions: VCC = VCC_RF = AVCC_RF = 3.3 V, VSS = VSS_RF = 0 V, T
a
= +25°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Input frequency RF
RXFIN_1M
2402 — 2480 MHz
Maximum input level RF
LEVL_1M
–10 4 — dBm *
1
Receiver sensitivity RF
STY_1M
—–95—dBm*
1
Secondary emission strength RF
RXSP_1M
— –72 –57 dBm 30MHz to 1GHz
— –54 –47 dBm 1GHz to 12GHz
Co-channel rejection ratio RF
CCR_1M
— –7 — dB Prf = –67dBm*
1
Adjacent channel rejection ratio RF
ADCR_1M
— –1 — dB Prf = –67dBm*
1
±1MHz
— 34 — dB ±2MHz
— 35 — dB ±3MHz
Blocking RF
BLK_1M
— 0 — dBm Prf = –67dBm*
1
30MHz to 2000MHz
— –24 — dBm 2000MHz to 2399MHz
— –20 — dBm 2484MHz to 3000MHz
— –4 — dBm > 3000MHz
Allowable frequency deviation*
2
RF
RXFER_1M
–120 — 120 ppm *
1
RSSI accuracy RF
RSSIS_1M
— ±4 — dB –70dBm ≤ Prf ≤ –10dBm
Table 51.64 Reception Characteristics
Conditions: VCC = VCC_RF = AVCC_RF = 3.3 V, VSS = VSS_RF = 0 V, T
a
= +25°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Input frequency RF
RXFIN_500k
2402 — 2480 MHz
Maximum input level RF
LEVL_500k
–10 4 — dBm *
1
Receiver sensitivity RF
STY_500k
— –100 — dBm *
1
Secondary emission strength RF
RXSP_500k
— –72 –57 dBm 30MHz to 1GHz
— –54 –47 dBm 1GHz to 12GHz
Co-channel rejection ratio RF
CCR_500k
— –4 — dB Prf = –72dBm*
1
Adjacent channel rejection ratio RF
ADCR_500k
— 6 — dB Prf = –72dBm*
1
±1MHz
— 36 — dB ±2MHz
— 42 — dB ±3MHz
Blocking RF
BLK_500k
— 0 — dBm Prf = –72dBm*
1
30MHz to 2000MHz
— –23 — dBm 2000MHz to 2399MHz
— –20 — dBm 2484MHz to 3000MHz
— –7 — dBm > 3000MHz
Allowable frequency deviation*
2
RF
RXFER_500k
–120 — 120 ppm *
1
RSSI accuracy RF
RSSIS_500k
— ±4 — dB –70dBm ≤ Prf ≤ –10dBm
