RX23W Group 9. Clock Generation Circuit
9. Clock Generation Circuit
9.1 Overview
This MCU incorporates a clock generation circuit.
Table 9.1 lists the specifications of the clock generation circuit. Figure 9.1 shows a block diagram of the clock
generation circuit.
Table 9.1 Specifications of Clock Generation Circuit (1/2)
Item Specification
Uses  Generates the system clock (ICLK) to be supplied to the CPU, DMAC, DTC, ROM, and RAM.
 Generates the peripheral module clocks (PCLKA, PCLKB, and PCLKD) to be supplied to
peripheral modules.
The peripheral module clock PCLKA is the operating clock for the MTU2, the peripheral module
clock PCLKD is for the S12AD, and PCLKB is for other modules.
 Generates the FlashIF clock (FCLK) to be supplied to the FlashIF.
 Generates the USB clock (UCLK) to be supplied to the USB.
 Generates the CAC clock (CACCLK) to be supplied to the CAC.
 Generates the RTC-dedicated sub-clock (RTCSCLK) to be supplied to the RTC.
 Generates the IWDT-dedicated low-speed clock (IWDTCLK) to be supplied to the IWDT.
 Generates the CAN clock (CANMCLK) to be supplied to the RSCAN.
 Generates the SSI clock (SSISCK) to be supplied to the SSI.
 Generates the LPT clock (LPTCLK) to be supplied to the LPT.
 Generation of Bluetooth-dedicated clock (BLECK)
 Generation of Bluetooth-dedicated low speed clock (BLELOCO)
Operating frequencies*
1
 ICLK: 54 MHz (max)
 PCLKA: 54 MHz (max)
 PCLKB: 32 MHz (max)
 PCLKD: 54 MHz (max)
 FCLK: 1 to 32 MHz (for programming and erasing the ROM and E2 DataFlash)
32 MHz (max) (for reading from the E2 DataFlash)
 UCLK: 48 MHz
 CACCLK: Same frequency as each oscillator
 RTCSCLK: 32.768 kHz
 IWDTCLK: 15 kHz
 CANMCLK: 20 MHz (max)
 SSISCK: 20 MHz (max)
 LPTCLK: The same frequency as that of the selected oscillator
 BLECK: 32 MHz
 BLELOCO: 32.768 kHz
Main clock oscillator*
2
 Resonator frequency: 1 to 20 MHz (VCC  2.4 V), 1 to 8 MHz (VCC < 2.4 V)
 External clock input frequency: 20 MHz (max)
 Connectable resonator or additional circuit: ceramic resonator, crystal
 Connection pins: EXTAL, XTAL
 Oscillation stop detection function:
When a main clock oscillation stop is detected, the system clock source is switched to LOCO
and MTU output can be forcedly driven to high-impedance.
 Drive capacity switching function
Sub-clock oscillator
 Resonator frequency: 32.768 kHz
 Connectable resonator or additional circuit: crystal
 Connection pin: XCIN, XCOUT
 Drive capacity switching function
PLL circuit*
3
 Input clock source: Main clock
 Input pulse frequency division ratio: Selectable from 1, 2, and 4
 Input frequency: 4 to 12.5 MHz
 Frequency multiplication ratio: Selectable from 4 to 13.5 (increments of 0.5)
 VCO oscillation frequency: 24 to 54 MHz (VCC  2.4 V)
USB-dedicated PLL circuit*
3
 Input clock source: Main clock
 Input pulse frequency division ratio: Selectable from 1, 2, and 4
 Input frequency: 4, 6, 8, and 12 MHz
 Frequency multiplication ratio: Selectable from 4, 6, 8, and 12
 VCO oscillation frequency: 48 MHz (VCC  2.4 V)
