R01UH0823EJ0100 Rev.1.00 Page 1131 of 1823
Jul 31, 2019
RX23W Group 35. I
2
C-bus Interface (RIICa)
35.2.8 I
2
C-bus Interrupt Enable Register (ICIER)
TMOIE Bit (Timeout Interrupt Request Enable)
This bit is used to enable or disable timeout interrupt (TMOI) requests when the ICSR2.TMOF flag is set to 1. A TMOI
interrupt request is canceled by setting the TMOF flag or the TMOIE bit to 0.
ALIE Bit (Arbitration-Lost Interrupt Request Enable)
This bit is used to enable or disable arbitration-lost interrupt (ALI) requests when the ICSR2.AL flag is set to 1. An ALI
interrupt request is canceled by setting the AL flag or the ALIE bit to 0.
STIE Bit (Start Condition Detection Interrupt Request Enable)
This bit is used to enable or disable start condition detection interrupt (STI) requests when the ICSR2.START flag is set
to 1. An STI interrupt request is canceled by setting the START flag or the STIE bit to 0.
SPIE Bit (Stop Condition Detection Interrupt Request Enable)
This bit is used to enable or disable stop condition detection interrupt (SPI) requests when the ICSR2.STOP flag is set to
1. An SPI interrupt request is canceled by setting the STOP flag or the SPIE bit to 0.
NAKIE Bit (NACK Reception Interrupt Request Enable)
This bit is used to enable or disable NACK reception interrupt (NAKI) requests when the ICSR2.NACKF flag is set to 1.
An NAKI interrupt request is canceled by setting the NACKF flag or the NAKIE bit to 0.
RIE Bit (Receive Data Full Interrupt Request Enable)
This bit is used to enable or disable receive data full interrupt (RXI) requests when the ICSR2.RDRF flag is set to 1.
Address(es): RIIC0.ICIER 0008 8307h
b7 b6 b5 b4 b3 b2 b1 b0
TIE TEIE RIE NAKIE SPIE STIE ALIE TMOIE
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 TMOIE Timeout Interrupt Request Enable 0: Timeout interrupt (TMOI) request is disabled.
1: Timeout interrupt (TMOI) request is enabled.
R/W
b1 ALIE Arbitration-Lost Interrupt Request
Enable
0: Arbitration-lost interrupt (ALI) request is disabled.
1: Arbitration-lost interrupt (ALI) request is enabled.
R/W
b2 STIE Start Condition Detection Interrupt
Request Enable
0: Start condition detection interrupt (STI) request is disabled.
1: Start condition detection interrupt (STI) request is enabled.
R/W
b3 SPIE Stop Condition Detection Interrupt
Request Enable
0: Stop condition detection interrupt (SPI) request is disabled.
1: Stop condition detection interrupt (SPI) request is enabled.
R/W
b4 NAKIE NACK Reception Interrupt Request
Enable
0: NACK reception interrupt (NAKI) request is disabled.
1: NACK reception interrupt (NAKI) request is enabled.
R/W
b5 RIE Receive Data Full Interrupt Request
Enable
0: Receive data full interrupt (RXI) request is disabled.
1: Receive data full interrupt (RXI) request is enabled.
R/W
b6 TEIE Transmit End Interrupt Request
Enable
0: Transmit end interrupt (TEI) request is disabled.
1: Transmit end interrupt (TEI) request is enabled.
R/W
b7 TIE Transmit Data Empty Interrupt
Request Enable
0: Transmit data empty interrupt (TXI) request is disabled.
1: Transmit data empty interrupt (TXI) request is enabled.
R/W
