Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 674 of 1823
Jul 31, 2019
RX23W Group 25. 16-Bit Timer Pulse Unit (TPUa)
25.2.4 Timer Interrupt Enable Register (TIER)
Note 1. These bits are reserved in TPU1, TPU2, TPU4, and TPU5. These bits are read as 0. The write value should be 0.
Note 2. This bit is reserved in TPU0 and TPU3. This bit is read as 0. The write value should be 0.
Note 3. This bit is reserved in TPU5. This bit is read as 0. The write value should be 0.
TTGE Bit (A/D Conversion Start Request Enable)
Enables/disables generation of A/D conversion start requests by TPUm.TGRA (m = 0 to 4) input capture/compare
match.
Address(es): TPU0.TIER 0008 8114h, TPU1.TIER 0008 8124h, TPU2.TIER 0008 8134h,
TPU3.TIER 0008 8144h, TPU4.TIER 0008 8154h, TPU5.TIER 0008 8164h
b7 b6 b5 b4 b3 b2 b1 b0
TTGE — TCIEU TCIEV TGIED TGIEC TGIEB TGIEA
Value after reset:
01000000
Bit Symbol Bit Name Description R/W
b0 TGIEA TGRA Interrupt Enable 0: Interrupt requests (TGImA) disabled
1: Interrupt requests (TGImA) enabled
(m = 0 to 5)
R/W
b1 TGIEB TGRB Interrupt Enable 0: Interrupt requests (TGImB) disabled
1: Interrupt requests (TGImB) enabled
(m = 0 to 5)
R/W
b2 TGIEC TGRC Interrupt Enable*
1
0: Interrupt requests (TGImC) disabled
1: Interrupt requests (TGImC) enabled
(m = 0, 3)
R/W
b3 TGIED TGRD Interrupt Enable*
1
0: Interrupt requests (TGImD) disabled
1: Interrupt requests (TGImD) enabled
(m = 0, 3)
R/W
b4 TCIEV Overflow Interrupt Enable 0: Interrupt requests (TCImV) disabled
1: Interrupt requests (TCImV) enabled
(m = 0 to 5)
R/W
b5 TCIEU Underflow Interrupt Enable*
2
0: Interrupt requests (TCImU) disabled
1: Interrupt requests (TCImU) enabled
(m = 1, 2, 4, 5)
R/W
b6 — Reserved This bit is read as 1. The write value should be 1. R/W
b7 TTGE A/D Conversion Start Request Enable*
3
0: A/D conversion start request generation disabled
1: A/D conversion start request generation enabled
R/W
