Page #788 background imageLoading...
Page #788 background image
R01UH0823EJ0100 Rev.1.00 Page 788 of 1823
Jul 31, 2019
RX23W Group 28. Realtime Clock (RTCe)
28.2.23 Minute Capture Register n (RMINCPn) (n = 0, 1)/BCNT1 Capture Register n
(BCNT1CPn) (n = 0, 1)
(1) In calendar count mode:
RMINCPn is a read-only register that captures the RMINCNT value when a time capture event is detected.
The event detection times detected by the RTCIC0 and RTCIC1 pins are stored in the RMINCP0 and RMINCP1
registers, respectively.
This register is set to 00h by an RTC software reset.
Before reading from this register, be sure to stop the time capture event detection through the setting of the
RTCCRn.TCCT[1:0] bits.
(2) In binary count mode:
BCNT1CPn is a read-only register that captures the BCNT1 value when a time capture event is detected.
The event detection times detected by the RTCIC0 and RTCIC1 pins are stored in the BCNT1CP0 and BCNT1CP1
registers, respectively.
This register is set to 00h by an RTC software reset.
Before reading from this register, be sure to stop the time capture event detection through the setting of the
RTCCRn.TCCT[1:0] bits.
Address(es): RTC.RMINCP0 0008 C454h, RTC.RMINCP1 0008 C464h
b7 b6 b5 b4 b3 b2 b1 b0
MIN10[2:0] MIN1[3:0]
Value after reset:
xxxxxxxx
x: Undefined
Bit Symbol Bit Name Description R/W
b3 to b0 MIN1[3:0] 1-Minute Capture Capture value for the ones place of minutes R
b6 to b4 MIN10[2:0] 10-Minute Capture Capture value for the tens place of minutes R
b7 Reserved This bit is read as 0 after an RTC software reset. R
Address(es): RTC.BCNT1CP0 0008 C454h, RTC.BCNT1CP1 0008 C464h
b7 b6 b5 b4 b3 b2 b1 b0
BCNTCPn[15:8]
Value after reset:
xxxxxxxx
x: Undefined
