Renesas RX Series User Manual

R01UH0823EJ0100 Rev.1.00 Page 1496 of 1823
Jul 31, 2019
RX23W Group 43. Capacitive Touch Sensing Unit (CTSU)
43.2.4 CTSU Sensor Stabilization Wait Control Register (CTSUSST)
The CTSUSST register should be set when the CTSUCR0.CTSUSTRT bit is 0.
CTSUSST[7:0] Bits (CTSU Sensor Stabilization Wait Control)
These bits set the stabilization wait time for the TSCAP pin voltage. The value of these bits should be fixed to
00010000b. If these bits are not set, the TSCAP voltage becomes unstable at the start of measurement, and the CTSU is
unable to obtain correct touch measurement results.
Address(es): CTSU.CTSUSST 000A 0903h
b7 b6 b5 b4 b3 b2 b1 b0
CTSUSST[7:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b7 to b0 CTSUSST[7:0] CTSU Sensor Stabilization Wait
Control
The value of these bits should be fixed to 00010000b. R/W
