R01UH0823EJ0100 Rev.1.00 Page 227 of 1823
Jul 31, 2019
RX23W Group 11. Low Power Consumption
11.2.3 Module Stop Control Register B (MSTPCRB)
Address(es): 0008 0014h
b31 b30 b29 b28 b27 b26 b25 b24 b23 b22 b21 b20 b19 b18 b17 b16
—
MSTPB
30
———
MSTPB
26
MSTPB
25
—
MSTPB
23
—
MSTPB
21
—
MSTPB
19
—
MSTPB
17
—
Value after reset:
1111111111111111
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
—————
MSTPB
10
MSTPB
9
——
MSTPB
6
—
MSTPB
4
———
MSTPB
0
Value after reset:
1111111111111111
Bit Symbol Bit Name Description R/W
b0 MSTPB0*
1
RSCAN0 Module Stop Target module: RSCAN0
0:This module clock is enabled
1: This module clock is disabled
R/W
b3 to b1 — Reserved These bits are read as 1. The write value should be 1. R/W
b4 MSTPB4 Serial Communication
Interface SCIh Module
Stop
Target module: SCIh (SCI12)
0: This module clock is enabled
1: This module clock is disabled
R/W
b5 — Reserved This bit is read as 1. The write value should be 1. R/W
b6 MSTPB6 DOC Module Stop Target module: DOC
0: This module clock is enabled
1: This module clock is disabled
R/W
b8, b7 — Reserved These bits are read as 1. The write value should be 1. R/W
b9 MSTPB9 ELC Module Stop Target module: ELC
0: This module clock is enabled
1: This module clock is disabled
R/W
b10 MSTPB10 Comparator B Module
Stop
Target module: Comparator B
0: This module clock is enabled
1: This module clock is disabled
R/W
b16 to b11 — Reserved These bits are read as 1. The write value should be 1. R/W
b17 MSTPB17 Serial Peripheral
Interface 0 Module Stop
Target module: RSPI0
0: This module clock is enabled
1: This module clock is disabled
R/W
b18 — Reserved This bit is read as 1. The write value should be 1. R/W
b19 MSTPB19
*
2
USB0 Module Stop Target module: USB0
0: This module clock is enabled
1: This module clock is disabled
R/W
b20 — Reserved This bit is read as 1. The write value should be 1. R/W
b21 MSTPB21 I
2
C Bus Interface 0
Module Stop
Target module: RIIC0
0: This module clock is enabled
1: This module clock is disabled
R/W
b22 — Reserved This bit is read as 1. The write value should be 1. R/W
b23 MSTPB23 CRC Calculator Module
Stop
Target module: CRC
0: This module clock is enabled
1: This module clock is disabled
R/W
b24 — Reserved This bit is read as 1. The write value should be 1. R/W
b25 MSTPB25 Bluetooth Low Energy
Module Stop
Target module: BLE
0: This module clock is enabled
1: This module clock is disabled
R/W
b26 MSTPB26 Serial Communication
Interface 5 Module Stop
Target module: SCI5
0: This module clock is enabled
1: This module clock is disabled
R/W
