R01UH0823EJ0100 Rev.1.00 Page 215 of 1823
Jul 31, 2019
RX23W Group 10. Clock Frequency Accuracy Measurement Circuit (CAC)
10.2.4 CAC Interrupt Request Enable Register (CAICR)
FERRIE Bit (Frequency Error Interrupt Request Enable)
This bit specifies whether the frequency error interrupt request is enabled or disabled.
MENDIE Bit (Measurement End Interrupt Request Enable)
This bit specifies whether the measurement end interrupt request is enabled or disabled.
OVFIE Bit (Overflow Interrupt Request Enable)
This bit specifies whether the overflow interrupt request is enabled or disabled.
FERRFCL Bit (FERRF Clear)
Setting this bit to 1 clears the CASTR.FERRF flag.
MENDFCL Bit (MENDF Clear)
Setting this bit to 1 clears the CASTR.MENDF flag.
OVFFCL Bit (OVFF Clear)
Setting this bit to 1 clears the CASTR.OVFF flag.
Address(es): 0008 B003h
b7 b6 b5 b4 b3 b2 b1 b0
—
OVFFC
L
MENDF
CL
FERRF
CL
—OVFIE
MENDI
E
FERRI
E
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 FERRIE Frequency Error Interrupt Request
Enable
0: Frequency error interrupt request is disabled.
1: Frequency error interrupt request is enabled.
R/W
b1 MENDIE Measurement End Interrupt
Request Enable
0: Measurement end interrupt request is disabled.
1: Measurement end interrupt request is enabled.
R/W
b2 OVFIE Overflow Interrupt Request Enable 0: Overflow interrupt request is disabled.
1: Overflow interrupt request is enabled.
R/W
b3 — Reserved This bit is read as 0. The write value should be 0. R/W
b4 FERRFCL FERRF Clear When 1 is written to this bit, the CASTR.FERRF flag is
cleared. This bit is read as 0.
R/W
b5 MENDFCL MENDF Clear When 1 is written to this bit, the CASTR.MENDF flag is
cleared. This bit is read as 0.
R/W
b6 OVFFCL OVFF Clear When 1 is written to this bit, the CASTR.OVFF flag is cleared.
This bit is read as 0.
R/W
b7 — Reserved This bit is read as 0. The write value should be 0. R/W
