36.2.53 Transmit/Receive FIFO Access Register 0CL (CFDF00)
Modify this register only when the CFCCH0.CFM[1:0] value is 01b.
This register is readable only when the CFCCH0.CFM[1:0] value is 00b. When the CFPTR0.CFDLC[3:0] value is
smaller than 1000b, data bytes for which no data is set are read as 00h.
This register can be read/written when the GRWCR.RPAGE bit is 1.
36.2.54 Transmit/Receive FIFO Access Register 0CH (CFDF10)
Modify this register only when the CFCCH0.CFM[1:0] value is 01b.
This register is readable only when the CFCCH0.CFM[1:0] value is 00b. When the CFPTR0.CFDLC[3:0] value is
smaller than 1000b, data bytes for which no data is set are read as 00h.
This register can be read/written when the GRWCR.RPAGE bit is 1.
Address(es): RSCAN0.CFDF00 000A 85E8h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CFDB1[7:0] CFDB0[7:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b7 to b0 CFDB0[7:0] Transmit/Receive FIFO Buffer
Data Byte 0
When CFCCH0.CFM[1:0] value is 01b (transmit mode):
Set the transmit/receive FIFO buffer data.
When CFCCH0.CFM[1:0] value is 00b (receive mode):
The message data stored in the transmit/receive FIFO buffer
can be read.
R/W
b15 to b8 CFDB1[7:0] Transmit/Receive FIFO Buffer
Data Byte 1
R/W
Address(es): RSCAN0.CFDF10 000A 85EAh
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CFDB3[7:0] CFDB2[7:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b7 to b0 CFDB2[7:0] Transmit/Receive FIFO Buffer
Data Byte 2
When CFCCH0.CFM[1:0] value is 01b (transmit mode):
Set the transmit/receive FIFO buffer data.
When CFCCH0.CFM[1:0] value is 00b (receive mode):
The message data stored in the transmit/receive FIFO buffer
can be read.
R/W
b15 to b8 CFDB3[7:0] Transmit/Receive FIFO Buffer
Data Byte 3
R/W
