RX23W Group 17. Memory-Protection Unit (MPU)
17.2.3 Memory-Protection Enable Register (MPEN)
MPEN Bit (Memory-Protection Enable)
This bit enables or disables the memory protection.
After 1 has been written to this bit, address checking for memory protection by the CPU starts on the execution of a
branch instruction (RTE or RTFI) that shifts operation to the user mode.
Address(es): 0008 6500h
b31 b30 b29 b28 b27 b26 b25 b24 b23 b22 b21 b20 b19 b18 b17 b16
————————————————
Value after reset:
0000000000000000
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
———————————————MPEN
Value after reset:
0000000000000000
Bit Symbol Bit Name Function R/W
b0 MPEN Memory-Protection Enable 1: The memory protection is enabled.
0: The memory protection is disabled.
R/W
b31 to b1 — Reserved The read value is 0. The write value should always be 0 R/W
