RX23W Group 48. Data Operation Circuit (DOC)

48.2.2 DOC Data Input Register (DODIR)

DODIR is a 16-bit readable/writable register in which 16-bit data for use in the operations are stored.

48.2.3 DOC Data Setting Register (DODSR)

DODSR is a 16-bit readable/writable register. This register stores 16-bit data for use as a reference in data comparison

mode. This register also stores the results of operations in data addition and data subtraction modes.

Address(es): 0008 B082h

b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0

Value after reset:

0000000000000000

Address(es): 0008 B084h

b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0

Value after reset:

0000000000000000
