R01UH0823EJ0100 Rev.1.00 Page 178 of 1823
Jul 31, 2019
RX23W Group 9. Clock Generation Circuit
9.2.6 USB-dedicated PLL Control Register 2 (UPLLCR2)
Note: Set the PRCR.PRC0 bit to 1 (write enabled) before rewriting this register.
The UPLLCR2 register runs or stops the USB-dedicated PLL circuit.
UPLLEN Bit (USB-dedicated PLL Stop Control)
This bit runs or stops the USB-dedicated PLL circuit.
After setting the UPLLEN bit to 0 (USB-dedicated PLL is operating), read the OSCOVFSR.UPLOVF flag to confirm
that it has become 1, and then start using the USB-dedicated PLL clock.
That is, a fixed time for stabilization is required after the setting for USB-dedicated PLL operation. A fixed time is also
required for oscillation to stop after the setting to stop USB-dedicated PLL operation. Accordingly, take note of the
following limitations when starting and stopping USB-dedicated PLL operation.
ï‚· After stopping the USB-dedicated PLL, confirm that the OSCOVFSR.UPLOVF bit is 0 before restarting the
USB-dedicated PLL.
ï‚· Confirm that the USB-dedicated PLL is operating and that the OSCOVFSR.UPLOVF bit is 1 before stopping the
USB-dedicated PLL.
ï‚· Regardless of whether or not it is selected as the system clock, confirm that the OSCOVFSR.UPLOVF bit is 1
before executing a WAIT instruction to place the MCU in software standby mode.
ï‚· After stopping the USB-dedicated PLL, confirm that the OSCOVFSR.UPLOVF bit is 0 and execute a WAIT
instruction before entering software standby mode.
When the external voltage (VCC) is below 2.4 V or low-speed operating mode is selected by the SOPCCR.SOPCM bit,
do not set the UPLLEN bit to 0 (USB-dedicated PLL is operating).
When the USB-dedicated PLL is selected by the UPLLCR.UCKUPLLSEL bit and the MSTPCRB.MSTPB19 bit is set to
0 (this module clock is enabled), do not set the UPLLEN bit to 1 (USB-dedicated PLL is stopped).
Address(es): 0008 002Eh
b7 b6 b5 b4 b3 b2 b1 b0
———————
UPLLE
N
Value after reset:
00000001
Bit Symbol Bit Name Description R/W
b0 UPLLEN USB-dedicated PLL Stop
Control
0: USB-dedicated PLL is operating.
1: USB-dedicated PLL is stopped.
R/W
b7 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
