R01UH0823EJ0100 Rev.1.00 Page 1544 of 1823

Jul 31, 2019

RX23W Group 44. 12-Bit A/D Converter (S12ADE)

44.2.7 A/D Channel Select Register B1 (ADANSB1)

ADANSB1 selects analog input channels for A/D conversion among AN016 to AN020 and AN027 in group B when

group scan mode is selected. The ADANSB1 register is not used in any scan mode other than group scan mode.

ANSB1n Bit (n = 00 to 04, 11) (A/D Conversion Channel Select)

The ANSB1n bit selects analog input channels for A/D conversion among AN016 to AN020 and AN027 in group B

when group scan mode is selected. The ADANSB1 register is used for group scan mode only; not used for any other

modes. The channels specified in group A (the channels corresponding to group A, selected with the ADANSA0 and

ADANSA1 registers and the ADCSR.DBLANS[4:0] bits in double trigger mode) should be excluded as the channels to

be selected and the number of channels to be set.

The ANSB100 bit corresponds to AN016 and the ANSB111 bit corresponds to AN027.

When performing A/D conversion of the temperature sensor output or internal reference voltage, do not select analog

input channels. The setting value of this register should be 0000h.

The ANSB1n bit should be set while the ADCSR.ADST bit is 0.

Address(es): S12AD.ADANSB1 0008 9016h

b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0

————

ANSB1

——————

ANSB1

Value after reset:

0000000000000000

Bit Symbol Bit Name Description R/W

b0 ANSB100 A/D Conversion Channel Select 0: AN016 to AN020 are not subjected to conversion.

1: AN016 to AN020 are subjected to conversion.

R/W

b1 ANSB101 R/W

b2 ANSB102 R/W

b3 ANSB103 R/W

b4 ANSB104 R/W

b10 to b5 — Reserved These bits are read as 0. The write value should be 0. R/W

b11 ANSB111 A/D Conversion Channel Select 0: AN027 is not subjected to conversion.

1: AN027 is subjected to conversion.

R/W

b15 to b12 — Reserved These bits are read as 0. The write value should be 0. R/W
