RX23W Group 36. CAN Module (RSCAN)
36.2.41 Receive FIFO Access Register mCL (RFDF0m) (m = 0, 1)
When the RFPTRm.RFDLC[3:0] value is smaller than 1000b, data bytes for which no data is set are read as 00h.
This register can be read when the GRWCR.RPAGE bit is 1.
36.2.42 Receive FIFO Access Register mCH (RFDF1m) (m = 0, 1)
When the RFPTRm.RFDLC[3:0] value is smaller than 1000b, data bytes for which no data is set are read as 00h.
This register can be read when the GRWCR.RPAGE bit is 1.
Address(es): RSCAN.RFDF00 000A 85A8h, RSCAN.RFDF01 000A 85B8h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RFDB1[7:0] RFDB0[7:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b7 to b0 RFDB0[7:0] Receive FIFO Buffer Data Byte 0 Data in the message stored in the receive FIFO buffer can
be read.
R
b15 to b8 RFDB1[7:0] Receive FIFO Buffer Data Byte 1 R
Address(es): RSCAN.RFDF10 000A 85AAh, RSCAN.RFDF11 000A 85BAh
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
RFDB3[7:0] RFDB2[7:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b7 to b0 RFDB2[7:0] Receive FIFO Buffer Data Byte 2 Data in the message stored in the receive FIFO buffer can
be read.
R
b15 to b8 RFDB3[7:0] Receive FIFO Buffer Data Byte 3 R
