R01UH0823EJ0100 Rev.1.00 Page 881 of 1823
Jul 31, 2019
RX23W Group 32. USB 2.0 Host/Function Module (USBc)
32.2.15 BRDY Interrupt Status Register (BRDYSTS)
Note 1. When the SOFCFG.BRDYM bit is set to 0, to clear the status indicated by the flags in the BRDYSTS register, write 0 only to the
flags to be cleared; write 1 to the other flags.
Note 2. When the SOFCFG.BRDYM bit is set to 0, clearing BRDY Interrupts should be done before accessing the FIFO.
Address(es): 000A 0046h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
——————
PIPE9B
RDY
PIPE8B
RDY
PIPE7B
RDY
PIPE6B
RDY
PIPE5B
RDY
PIPE4B
RDY
PIPE3B
RDY
PIPE2B
RDY
PIPE1B
RDY
PIPE0B
RDY
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 PIPE0BRDY BRDY Interrupt Status Flag for
PIPE0*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b1 PIPE1BRDY BRDY Interrupt Status Flag for
PIPE1*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b2 PIPE2BRDY BRDY Interrupt Status Flag for
PIPE2*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b3 PIPE3BRDY BRDY Interrupt Status Flag for
PIPE3*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b4 PIPE4BRDY BRDY Interrupt Status Flag for
PIPE4*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b5 PIPE5BRDY BRDY Interrupt Status Flag for
PIPE5*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b6 PIPE6BRDY BRDY Interrupt Status Flag for
PIPE6*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b7 PIPE7BRDY BRDY Interrupt Status Flag for
PIPE7*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b8 PIPE8BRDY BRDY Interrupt Status Flag for
PIPE8*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b9 PIPE9BRDY BRDY Interrupt Status Flag for
PIPE9*
2
0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*
1
b15 to b10 — Reserved These bits are read as 0. The write value should be 0. R/W
