RX23W Group 46. Temperature Sensor (TEMPSA)

46. Temperature Sensor (TEMPSA)

46.1 Overview

This MCU includes a temperature sensor. The temperature sensor outputs a voltage which varies with the temperature.

The user can obtain the temperature surrounding the MCU using the 12-bit A/D converter to convert the voltage output

from the temperature sensor into a digital value.

Table 46.1 lists the specifications of the temperature sensor. Figure 46.1 shows a overall block diagram of the

temperature sensor system.

Figure 46.1 Block Diagram of Temperature Sensor System

Table 46.1 Temperature Sensor Specifications

Item Description

Temperature sensor voltage output The temperature sensor voltage is output to the 12-bit A/D converter.

Temperature sensor

Internal reference

voltage

Analog multiplexer

Control circuit

12-bit A/D converter
