R01UH0823EJ0100 Rev.1.00 Page 1207 of 1823
Jul 31, 2019
RX23W Group 36. CAN Module (RSCAN)
36.2.12 Global Control Register H (GCTRH)
TSRST Bit (Timestamp Counter Reset)
This bit is used to reset the timestamp counter. When this bit is set to 1, the GTSC register is set to 0000h.
36.2.13 Global Status Register (GSTS)
GRSTSTS Flag (Global Reset Status Flag)
This flag becomes 1 when the CAN module has transitioned to global reset mode, and becomes 0 when the CAN module
has exited global reset mode. This flag remains 1 even when the CAN module has transitioned from global reset mode to
global stop mode.
GHLTSTS Flag (Global Test Status Flag)
This flag becomes 1 when the CAN module has transitioned to global test mode, and becomes 0 when the CAN module
has exited global test mode.
GSLPSTS Flag (Global Stop Status Flag)
This flag becomes 1 when the CAN module has transitioned to global stop mode, and becomes 0 when the CAN module
Address(es): RSCAN.GCTRH 000A 8328h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
———————————————TSRST
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 TSRST Timestamp Counter Reset Setting the TSRST bit to 1 resets the timestamp counter.
This bit is read as 0.
R/W
b15 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
Address(es): RSCAN.GSTS 000A 832Ah
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
————————————
GRAMI
NIT
GSLPS
TS
GHLTS
TS
GRSTS
TS
Value after reset:
0000000000001101
Bit Symbol Bit Name Description R/W
b0 GRSTSTS Global Reset Status Flag 0: Not in global reset mode
1: In global reset mode
R
b1 GHLTSTS Global Test Status Flag 0: Not in global test mode
1: In global test mode
R
b2 GSLPSTS Global Stop Status Flag 0: Not in global stop mode
1: In global stop mode
R
b3 GRAMINIT CAN RAM Initialization Status
Flag
0: CAN RAM initialization is completed.
1: CAN RAM initialization is ongoing.
R
b15 to b4 — Reserved These bits are read as 0. R
