R01UH0823EJ0100 Rev.1.00 Page 882 of 1823
Jul 31, 2019
RX23W Group 32. USB 2.0 Host/Function Module (USBc)
32.2.16 NRDY Interrupt Status Register (NRDYSTS)
Note 1. To clear the status indicated by the flags in the NRDYSTS register, write 0 only to the flags to be cleared; write 1 to the other
flags.
Address(es): 000A 0048h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
——————
PIPE9N
RDY
PIPE8N
RDY
PIPE7N
RDY
PIPE6N
RDY
PIPE5N
RDY
PIPE4N
RDY
PIPE3N
RDY
PIPE2N
RDY
PIPE1N
RDY
PIPE0N
RDY
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b0 PIPE0NRDY NRDY Interrupt Status Flag for PIPE0 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b1 PIPE1NRDY NRDY Interrupt Status Flag for PIPE1 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b2 PIPE2NRDY NRDY Interrupt Status Flag for PIPE2 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b3 PIPE3NRDY NRDY Interrupt Status Flag for PIPE3 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b4 PIPE4NRDY NRDY Interrupt Status Flag for PIPE4 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b5 PIPE5NRDY NRDY Interrupt Status Flag for PIPE5 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b6 PIPE6NRDY NRDY Interrupt Status Flag for PIPE6 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b7 PIPE7NRDY NRDY Interrupt Status Flag for PIPE7 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b8 PIPE8NRDY NRDY Interrupt Status Flag for PIPE8 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b9 PIPE9NRDY NRDY Interrupt Status Flag for PIPE9 0: Interrupts are not generated.
1: Interrupts are generated.
R/W
*1
b15 to b10 — Reserved These bits are read as 0. The write value should be 0. R/W
