RX23W Group 33. Serial Communications Interface (SCIg, SCIh)
33.2.36 Timer Control Register (TCR)
33.2.37 Timer Mode Register (TMR)
Note 1. Rewrite the TOMS[1:0] and TCSS[2:0] bits only when the timer is stopped (TCST = 0).
TWRC Bit (Counter Write Control)
This bit determines whether a value written to TPRE or TCNT is written to the reload register only or is written to both
the reload register and the counter.
Address(es): SCI12.TCR 0008 B330h
b7 b6 b5 b4 b3 b2 b1 b0
———————TCST
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b0 TCST Timer Count Start 0: Stops the timer counting
1: Starts the timer counting
R/W
b7 to b1 — Reserved These bits are read as 0. The write value should be 0. R/W
Address(es): SCI12.TMR 0008 B331h
b7 b6 b5 b4 b3 b2 b1 b0
— TCSS[2:0] TWRC — TOMS[1:0]
Value after reset:
00000000
Bit Symbol Bit Name Description R/W
b1, b0 TOMS[1:0] Timer Operating Mode Select*
1
b1 b0
0 0: Timer mode
0 1: Break Field low width determination mode
1 0: Break Field low width output mode
1 1: Setting prohibited
R/W
b2 — Reserved This bit is read as 0. The write value should be 0. R/W
b3 TWRC Counter Write Control 0: Data is written to the reload register and counter
1: Data is written to the reload register only
R/W
b6 to b4 TCSS[2:0] Timer Count Clock Source Select*
1
b6 b4
0 0 0: PCLK
0 0 1: PCLK/2
0 1 0: PCLK/4
0 1 1: PCLK/8
1 0 0: PCLK/16
1 0 1: PCLK/32
1 1 0: PCLK/64
1 1 1: PCLK/128
R/W
b7 — Reserved This bit is read as 0. The write value should be 0. R/W
