RX23W Group 36. CAN Module (RSCAN)
36.2.49 Transmit/Receive FIFO Access Register 0AL (CFIDL0)
Modify this register only when the CFCCH0.CFM[1:0] value is 01b (transmit mode). This register is readable only when
the CFCCH0.CFM[1:0] value is 00b (receive mode).
This register can be read/written when the GRWCR.RPAGE bit is 1.
CFID[15:0] Bits (Transmit/Receive FIFO Buffer ID Data L)
These bits indicate the ID of the received message stored in the transmit/receive FIFO buffer when the
CFCCH0.CFM[1:0] value is 00b.
When the CFCCH0.CFM[1:0] value is 01b, set the ID of the message to be transmitted from the transmit/receive FIFO
buffer.
Address(es): RSCAN0.CFIDL0 000A 85E0h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
CFID[15:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b15 to b0 CFID[15:0] Transmit/Receive FIFO Buffer
ID Data L
When CFCCH0.CFM[1:0] value is 01b (transmit mode):
Set standard ID or extended ID. For standard ID, write an ID
to b10 to b0 and write 0 to b15 to b11.
When CFCCH0.CFM[1:0] value is 00b (receive mode):
Standard ID or extended ID in the received message can be
read. For standard ID, read b10 to b0. The value read from
b15 to b11 are 0.
R/W
