R01UH0823EJ0100 Rev.1.00 Page 313 of 1823
Jul 31, 2019
RX23W Group 16. Buses
16.3.5 Bus Priority Control Register (BUSPRI)
Note 1. These bits can be written to only once while the DTC and DMAC are stopped. When they are written to more than one time, the
operation is not guaranteed.
BPRA[1:0] Bits (Memory Bus 1 (RAM) Priority Control)
These bits specify the priority order for memory bus 1 (RAM).
When the priority order is fixed, internal main bus 2 has priority over internal main bus 1.
When the priority order is toggled, a bus has a lower priority when the request of that bus is accepted.
BPRO[1:0] Bits (Memory Bus 2 (ROM) Priority Control)
These bits specify the priority order for memory bus 2 (ROM).
When the priority order is fixed, internal main bus 2 has priority over internal main bus 1.
When the priority order is toggled, a bus has a lower priority when the request of that bus is accepted.
BPIB[1:0] Bits (Internal Peripheral Bus 1 Priority Control)
These bits specify the priority order for internal peripheral bus 1.
When the priority order is fixed, internal main bus 2 has priority over internal main bus 1.
Address(es): 0008 1310h
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
———— BPFB[1:0] BPHB[1:0] BPGB[1:0] BPIB[1:0] BPRO[1:0] BPRA[1:0]
Value after reset:
0000000000000000
Bit Symbol Bit Name Description R/W
b1, b0 BPRA[1:0] Memory Bus 1 (RAM) Priority
Control
b1 b0
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b3, b2 BPRO[1:0] Memory Bus 2 (ROM) Priority
Control
b3 b2
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b5, b4 BPIB[1:0] Internal Peripheral Bus 1 Priority
Control
b5 b4
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b7, b6 BPGB[1:0] Internal Peripheral Bus 2 and 3
Priority Control
b7 b6
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b9, b8 BPHB[1:0] Internal Peripheral Bus 4 Priority
Control
b9 b8
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b11, b10 BPFB[1:0] Internal Peripheral Bus 6 Priority
Control
b11 b10
0 0: The order of priority is fixed.
0 1: The order of priority is toggled.
1 0: Setting prohibited
1 1: Setting prohibited
R(/W)
*
1
b15, b12 — Reserved These bits are read as 0. The write value should be 0. R/W
